| Dimensions | 268.1 x 136.5 x 31.1 mm (10.55 x 5.37 x 1.22") |
| Weight | 600 g (1.32 lb) |
| Networking Interface | (10) 10/100/1000 RJ45 Ports |
| Buttons | Reset |
| Power Method | External AC/DC Power Adapter, 24W (24V, 1A) (Included) 24V Passive PoE |
| Power Supply | External AC/DC Adapter |
| Maximum Power Consumption | 8W (Excludes PoE Output) |
| Certifications | CE, FCC, IC |
| Mounting | Wall, Rack* |
| Operating Temperature | -10 to 45° C (14 to 113° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Processor | Dual-Core 880 MHz, MIPS1004Kc |
| Memory | 512 MB DDR3 RAM |
| Management Interface | (1) RJ45 Serial Port (10) Ethernet Ports (Default Port 0) |
| Data Port | Link/Activity, PoE (Port 9 Only) |
| Supported Voltage Range | 9 - 30VDC 20 - 30V |
| Layer 3 Forwarding Performance Packet Size: 64 Bytes Packet Size: 512 Bytes or Larger | 260,000 pps 1 Gbps (Line Rate) |
| On-Board Flash Storage | 512 MB NAND |
